AE070100

Manufacturer Warranty

Click Here To View Manufacturer Warranty

CLUTTER INTO PROFIT

clutterInto

Turn your used or unwanted transformers or circuit breakers into cash or credit

Equipment Purchase Program

AE070100

AE070100

SKU:AE070100

By : ACME

ADD TO QUOTE
safeCheckout

Description

The Acme Electric AE070100 AE Series Dry type 100KVA Industrial Control Transformers are designed for machine tool control circuits, handling high in-rush currents while maintaining stable output voltage. Supporting primary voltages of 208V, 230V, and 460V with an 115V secondary voltage, this 100KVA transformer features durable copper windings and an open-style enclosure. It meets or exceeds international standards, making it ideal for demanding industrial applications requiring reliable performance.

Key features of Acme AE070100 Transformer:

• Safeguards components from surge damage.
• Maintains consistent output power.
• Handles diverse industrial loads.
• Efficient cooling, easy access.
• Optimal performance and efficiency.
• Versatile input voltage options.
• Ideal output voltage for control circuits.

ACME

Additional information

  • DIMENSIONS

    3.09 × 3.41 × 3.41 in

  • KVA:

    100

  • PHASE:

    SINGLE

  • PRIMARY VOLTAGE:

    208/230/460

  • SECONDARY VOLTAGE:

    115

  • WINDING MATERIAL:

    COPPER

  • HZ:

    50/60

  • TEMP RISE:

    55

  • ENCLOSURE:

    OPEN STYLE

  • TYPE:

    AE SERIES INDUSTRIAL CONTROL TRANSFORMERS

  • OLD PART NUMBER:

    AE07-0100

  • Weight

    4.2 lsb
